The RB711GA-5HnD is a small AP type RouterBOARD 5GHz wireless router with an integrated wireless card. It has two antenna connectors for using in dual chain setups, and a Gigabit Ethernet port - the perfect device for Nv2!
The integrated 5GHz 802.11a/n wireless card is capable of up to 25dBm! It has built in 16kV ESD protection on both the RF and Ethernet ports.
Supported frequency:
4800-6075Mhz
Details | |
---|---|
Product code | RB711GA-5HnD |
CPU nominal frequency | 400 MHz |
CPU core count | 1 |
Size of RAM | 64 MB |
10/100 Ethernet ports | 0 |
10/100/1000 Ethernet ports | 1 |
MiniPCI slots | 0 |
MiniPCI-e slots | 0 |
Wireless chip model | 1 |
Wireless standards | 802.11an |
Number of USB ports | 1 |
Power Jack | Yes |
PoE in | 8-30V |
Voltage Monitor | Yes |
PCB temperature monitor | Yes |
CPU temperature monitor | No |
Dimensions | 10.5 cm x 10.5 cm |
Operating System | RouterOS |
Operating temperature range | -30 .. +65C |
License level | Level 4 |
Current Monitor | No |
CPU | Atheros AR7241 |
SFP ports | 0 |
